VM15 User Manual Description of Display and Symbols
28
Electrical
The Raged voltage is 100-240VAC, 50/60 Hz. If the input power supply has the trouble, the
fuse will protect the patient from the trouble.
High capacity Battery (Li-ion Battery) can be installed maximum two pieces (one additional
as option.) The standard battery can last 2 hours without AC power supply. (without printing
& at room temperature) The remaining battery capacity is shown on the upper side of the
screen.
Battery can be easily equipped and disconnected. The recharge starts when it is connected
with AC power supply (100-240VAC, 50/60Hz)
Display
VM15 display the vital signs on 15 Inch (VM15) Color TFT LCD monitor. The users can easily
operate the function or setting of the patient monitor with Touch Screen. 12 kind of vital
sign wave and measured value are displayed on the monitor at real time.
In addition, convenient menu processing using the touch screen and encoder, it displays the
patient's vital sign in real time, and displays the trend function and various warning messages
that store and display the past vital sign.
Auxiliary Outputs
NOTE : The following applies only to STD1.
The Transport Module (ESN Module Box) can be separated from the products. Transport
Module can be used at bed side if it has the extension cable.
In addition, it is possible to check the patient's vital sign through an external device by
connecting to a monitor with a VGA port through the VM15's Video Output Port.
WARNING: All ports and sockets are not allowed to connect with non-allowed use. The
manufacturer and the distributors will not take any responsibility for the damage or losses
occurred by the misuse of the users.
