VM15 User Manual ECG Monitoring
112
SETTING Function
ST: ST J+ 0, 20, 30, 40, 50, 60, 70, 80ms.
PACEMAKER: OFF, ON.
ARRHYHMIA: OFF or ON
HR ALARM
Alarm setting to be done for each Alarm
⚫ HIGH alarm set: 0-300, OFF.
⚫ LOW alarm set: OFF, 0~300.
⚫ TYPE alarm set: HIGH, MEDIUM, LOW, OFF.
FILTER
Notch can set 50Hz, 60Hz, OFF.
Filter can set 0.5~40Hz, 0.5~80Hz, 0.05~40Hz, 0.05~80Hz, Monitoring.
ST ALARM Function
Alarm ST1 ~ ST7, TYPE with 5 Lead Cable. (EKG Option: ST V2 ~ ST V6)
Alarm ST1~ST3, type WITH 3 Lead Cable.
5Lead cable measures 7 data (ST I ~ ST V1). (EKG Cable measures add 5 data (ST V2 ~ ST V6)
3 Lead Cable measures 3 data (ST I ~ ST III)
Alarm setting to be done for each Alarm
⚫ HIGH alarm set: -9.9 ~ 9.9, OFF.
⚫ LOW alarm set: OFF, -9.9 ~ 9.9, OFF.
⚫ TYPE alarm set: HIGH, MEDIUM, LOW, OFF.
SETUP TM
NOTE : The following applies only to STD1.
Leads have 1 kind: CH1
CH1 can set SPEED 6.25, 12.5, 25, 50mm/sec.
CH1 can set GAIN 2.5, 5, 10, 20, 40mm/mV.
CH1 can set LEAD I, II, III, aVR, aVL, aVF, V1. (EKG Option: V2~V6 add)
If the user selects 3 Lead, the user can select one wave among ECG I, II, III wave.
