VM15 User Manual Explanation of ICO (Option)
158
General
The blood presser is higher because the blood vessel has more bloods than its capacity by
the systole of the ventricles of the heart. The blood pressure at this time is called as systolic
blood pressure.
The blood pressure of ventricles of the heart becomes lower when the ventricle of the hearts
is dilating. The blood pressure at this time is call as diastolic blood pressure.
The sensor detects the press at these times. And the figures are displayed on the screen.
Setup Connection
How to connect the accessory
The below picture is IBP Cable.
The part with dot circle is to be connected with IBP socket at the monitor.
Figure 23-1. IBP Cable
Connect IBP Cable to the IBP Socket at the left side of the monitor like Figure 36. The color
is blue.
Figure 23-2. IBP Cable Connection
