VOTEM VM15 - Description of NIBP Functions

VM15 User Manual Suntech NExplanation of ICO (Option)
154
MEASUREMENT
TIME LIMIT
The patient may have been moving too much.
Check that the cuff is properly tightened.
Check that the cuff is in the correct position.
Check that the correct size cuff is being applied.
Check that there is no excessive clothing between the arm
and the cuff.
PNEUMATIC
BLOCKAGE
Check that the hose has no sharp bends or is pinched.
Check that the patient is not lying on the cuff.
Check that the cuff is in the correct position
INFLATE TIMEOUT
Check that the hose is connected to the system and the cuff.
Check that the cuff is properly tightened.
Check that the cuff is in the correct position.
Check that the correct size cuff is being applied.
Check that the cuff is not leaking air.
Check that the hose connections are not damaged or loose.
SAFETY TIMEOUT
Check the patient.
To reset the safety timer and continue taking BP measurements,
Perform the instructions in section 5.5 or cycle the logic power to
the module.
Check that the cuff is in the correct position.
The patient may have been moving too much.
Take another BP reading.
OVER PRESSURE
Check that the correct size cuff is being applied.
Check that the hose has no sharp bends or is pinched.
Check that the cuff is in the correct position.
Check that the patient is not lying on the cuff.
HARDWARE ERROR
Check that Vpump and Vlogic are within the voltage
specifications.
Check the data/power input connection.
If applicable, check that sleep mode operation is correct.
Service may be required. Call a SunTech representative.
Description of NIBP functions
SUNTECH NIBP Menu appears when the user selects NIBP Measurement Screen in Numeric
area.
Press “X” and NIBP menu disappears. (Refer to the below Figure 20-4.)
Figure 22-2. DISPLAYS - NIBP Menu
