VM15 User Manual Specification
251
TREND
⚫ Popup Screen
◼ Text Trend
◼ Graph Trend
⚫ Interval Time: 1, 5, 10 minutes
⚫ Parameter
◼ HR (Heart Rate), SpO2, Resp (Respiration), NIBP (Sys, Dia, Mean),
◼ 4ch IBP, 4ch Temp, ST Segment, EtCO2, Multi Gas, qCON.
⚫ 7 Days Trend Data Save
Interface
⚫ RS-232C port (for service port only)
⚫ LAN Port (10/100/1000Mbps)
⚫ USB Port (for Software Update)
⚫ VGAOUT (Optional)
⚫ ECG Output (Optional)
Physical Specifications(STD1)
⚫ Size: 283 x 414 x 229 mm (W x D x H)
⚫ Weight: 8.5kg (with VM15 Standard)
⚫ Power Requirement: 1.2A, 100-240V~, 50/60Hz
⚫ Power consumption: 90VA (MAX)
⚫ Battery
◼ Recharge Time: 12 hours
◼ Storage Temperature (Only Battery)
◆ 1 year: -20 to 25 ℃
◆ 3 months: -20 to 45 ℃
◆ 1 month: -20 to 60 ℃
◼ VM15 STD1 Discharge Time
◆ Performance Specification (1 Pack): 10.89VDC, 5200mAh
◆ 1 Pack: Basic monitoring configuration 2 Hours (Standard)
◆ 2 Pack: Basic monitoring configuration 4 Hours (Optional)
◼ TM (Transport Module) Part Discharge Time – Used to TM only
◆ Performance Specification (1 Pack): 10.89VDC, 2600mAh
◆ 1 Pack: Basic monitoring configuration 1 Hours (Standard)
