VOTEM VM15 - ICO (Cardiac Output) - Optional

VM15 User Manual Specification
243
ICO (Cardiac Output) - Optional
⚫ Measurement Method: Thermodilution
⚫ Measurement Range: 0.1 ~ 20 L/min
⚫ Repeatability: ±5% or ± 0.2 L/min, which is greater
⚫ Injectate Temperature Range: 0℃ or 24 ℃
⚫ Blood Temperature Range: 33 ~ 39 ℃
⚫ Injectate Volume: 10 cc only
⚫ Catheter
◼ Swan-Ganz Standard Thermodilution Pulmonary Artery Catheter
(Edward's Life Sciences)
⚫ Hemodynamic Parameters
◼ Input/Measured Data from VM15
◆ CO: Cardiac Output (L/min)
◆ HR: Heart Rate (bpm)
◆ MAP: Mean Arterial Pressure (mmHg)
◆ CVP: Central Venous Pressure (mmHg)
◆ PAM: Pulmonary Artery Mean Pressure (mmHg)
◆ PAW: Pulmonary Artery Wedge Pressure (mmHg)
◆ PAD: Pulmonary Artery Diastolic Pressure (mmHg)
◆ LA: Left Atrium Pressure (mmHg)
◆ WEIGHT: Weight (kg)
◆ HEIGHT: height (cm)
◼ Calculated Data
◆ BSA: Body Surface Area (m
2
)
◆ CI: Cardiac Index (L/min/m
2
)
◆ SV: Stroke Volume (mL/beat)
◆ SVR: Systemic Vascular Resistance (dny*sec*cm
-2
)
◆ SVRI: Systemic Vascular Resistance Index (dny*sec*cm
-5
*m
2
)
◆ PVR: Pulmonary Vascular Resistance (dny*sec*cm
-5
)
◆ PVRI: Pulmonary Vascular Resistance Index (dny*sec*cm
-5
*m
2
)
◆ LVSWI: Left Ventricular Stroke Work Index (g*m/m
2
)
◆ RVSWI: Right Ventricular Stroke Work Index (g*m/m
2
)
