How to Priming use
⚫ Priming should be done slowly.
The user shall have less efforts of removing the bubble
afterwards.
⚫ Do priming with Gravity.
During the input, the liquid may leaks or the bubble may occur.
Pull up the supplying back when the little bubble flows too
slowly. 1 (one) inch is 2mmHg. Primed 4 feet line puts the press
of approximately 100mm Hg when it completely spread out.
Solution Bag should be at higher location than changer and
pressure tube for priming with gravity.
Way of measuring
Set the zero pint of changer.
Lock (off direction) Zero Stop Cock. Do outlet the changer with the air pressure.
Figure 23-8. Stop Cock
For the correctness, do zeroing calibration. by selecting IBP MENU – ZERO.
