VM15 User Manual Masimo SpO2 Monitoring (Option)
140
BOARD FAILURE
- DSP Checksum Fail
- DSP Program Memory Test Fail
- DSP Data Memory Test Fail
- DSP Detector ADC Intrpt Test Fail
- DSP MCU Intrpt Fail
- DSP Diag Queue Overrun
- DSP Hardware Status Fail
- DSP Raw Queue Overrun
- DSP MCU Watchdog Fail
- DSP Invalid MC State
- DSP Diagnostic Fail
Unit requires service.
DIAGNOSTIC FAILURE
- LED Ground
- Reference Voltage
- Digital Voltage
- DSP Voltage
- Analog Voltage
- LED Current
- Analog Ground
- LED Drive Voltage
- Sensor ID
Unit requires service.
