Table 33-1. TM Description
No
Name
Function
Note
1
SPEAKER
Sound measurement information
2
4.3inch LCD
4.3inch LCD
3
Alarm
Pause the alarm sound when an alarm condition occurs. (2
minutes)
4
NIBP
Button to start/stop non-invasive blood pressure measurement
5
Power Switch
Turn the operation On / Off.
6
Power LED
Power LED
LED color
- Connect to main body using AC power : Green
- Connect to a battery-operated body : Orange
- Separated from the main body (Battery operated) : Orange
7
EKG connector
Connector to connect EKG
Option
8
SpO2 connector
Connector to measure SpO2
Masimo-
Option
9
TEMP 1 connector
Connector for measuring TEMP1
10
ECG OUT connector
Connector to connect ECG OUT
Option
11
RESET
Button for RESET ESN Module
12
NIBP connector
Connection port for non-invasive blood pressure measurement
Suntech-
Option
13
ECG connector
Connector to connect ECG
Note: When the TM is connected to the main unit, pressing the TM front button does not
work.
Note: When the TM is connected to the main unit, the TM front speakers do not work.
