VM15 User Manual Reviewing Trends
87
When this button is pressed, the event wave data start position moves -4
seconds from the current position.
When this button is pressed, the event wave data start position moves +4
seconds from the current position.
Move the position of event wave data to the end position (10sec).
(Event wave data is a total of 20 seconds data for 10 seconds before and after
the event occurs, and this button moves to the position 10 seconds after the
event occurs.)
Delete all saved event data.
In the Event window, you can review the wave data of 5 parameters.
In this menu, the user can specify the desired parameters for each of the 5
traces
Event data can be printed through the printer attached to the product
The printer can print 3 channels of wave data. In this menu, you can specify
wave data to be printed on 3 channels
Press this button to start printing Event data.
Note. In the Event screen, focus on the area marked (<>) between menu buttons, press
the Encoder once.
You can use the encoder to adjust the position of the wave data.
