WEILER E2850 REMIXING TRANSFER VEHICLE
3-51
Operating Instructions
3
Machine Cleanup
8. Slowly lower elevator until cylinder stops are firmly
in contact with ends of cylinder tubes (7).
9. Install cylinder stop latch pins (8).
10. Run elevator in reverse to remove material from
chute. The material will discharge out of cleanout
door opening.
11. Turn engine off and remove ignition key. Clean
material off of door. Clean sealing edges of door and
opening thoroughly to enable door to fully close.
12. To close and latch cleanout door, reverse the steps
used to open the door.
13. Turn engine on and lower elevator until cleanout door closes. Verify material is not keeping door
from closing.
If equipped with optional windrow attachment, raise elevator and then lower and latch
dropdown supports so windrow attachment can be lowered to the ground.
8
7
