Weiler E2850 - Page 224

Schematics
C
WEILER E2850 REMIXING TRANSFER VEHICLE
C-32
Schematics
ELECTRICAL SCHEMATIC – S/N 1141–1144
2-WH
3-BU
1
CAMERA
5A 6159
CAMERA (OPT)
5-WH w/YL
2A
CAMERA
1-RD
4-BR
6-GY
ORANGE 3931
PUSH ROLLER 6128
3
PUSH ROLLER 6128
HOPPER CLEAN OUT 6128 HOPPER CLEAN OUT 6128
TRUCK HITCH (OPT) 6128
SPRAY DOWN 6129
REMOTE TRUCK HITCH 6128 REMOTE TRUCK HITCH 6128
2
2 2
2
2
2
2
2
3
1
3 1 3 1
1
3
1
3
1
3
1
TRUCK HITCH OPTION
3 3
ELEV BAFFLE 6128
3
REMOTE VIBRATOR 6132
REMOTE ELEV BAFFLE 6128 REMOTE ELEV BAFFLE 6128
HORN HORN HORN
ORANGE 3931
VIBRATOR 6132
ORANGE 3931
REMOTE VIBRATOR 6132
2 2 2
2 2 2
1 1 1
3
1
PUSH ROLLER IN "A" COIL
PUSH ROLLER OUT "B" COIL
HOPPER CLEAN OUT CLOSE "B" COIL
HOPPER CLEAN OUT OPEN "A" COIL
TRUCK HITCH OPEN "A" COIL
SPRAY DOWN
DC MOTOR
TRUCK HITCH CLOSE "B" COIL
2A 2A 2A
3.5A
2A
M
2A
BAFFLE CLOSE "B" COIL
BAFFLE OPEN "A" COIL
FRT HORN 8160
VIBRATOR
RR HORN 8160
2A 2A 2A 2A
3 3 3
HOPPER DUMP 6128
REMOTE HOPPER DUMP 6128 REMOTE HOPPER DUMP 6128
2 2 2
1 1 1
HOPPER LOWER "B" COIL
HOPPER RAISE "A" COIL
2A
TO BAFFLE SWITCH TO BAFFLE SWITCH TO BAFFLE SWITCH
TO RH CONTROL CB-5A
75-BU w/RD
2-RD
180-RD
71-OR w/BK 71-OR w/BK
60-OR w/BK
68-GN 67-BR 52-GY
51-PK
74-TN w/BK
79-YL
65-TN w/RD 66-BU w/RD
80-YL w/RD
69-TN
63-BR w/RD
64-PU w/WH
FROM PAGE 4
FROM PAGE 4
FROM PAGE 4
PAGE 5
