Weiler E2850 - Page 243

Schematics
C
WEILER E2850 REMIXING TRANSFER VEHICLE
C-51
Schematics
ELECTRICAL SCHEMATIC – S/N 1150–1153
LED STROBE
2A
6129
STROBE
2
1
3A 3A 3A 3A 3A
LH DASH LAMP
RH REMOTE DASH LAMP
30A 6160
LOC-ENG
30A 6160
LOC-ENG
WORK LIGHTS
& STROBE
HOPPER LIGHTS
6129
LIGHTING GROUP (OPT)
6129
6129
REAR WORK LIGHT
2
1
HEAD LIGHTS
2
1
6129
HOPPER LIGHTS
2
1
3A
3A
3A 3A 3A 3A 3A
DASH LIGHTS
2
1
(4449/8170) (4449/8170)
LH REMOTE DASH LAMP
(C3166409)
ENGINE DASH LAMP
(C3166409)
RH DASH LAMP
(C3166409)
CENTER DASH LAMP
(C3166409)
(C3381132)
(C2344323/26526)
RH CONVEYOR
(C2344323/26526)
LH CONVEYOR
(C2344323/26526)
RH GROUND REAR LH GROUND REAR
(C2344323/26526)
RH REAR
(C2344323/26526) (C2344323/26526)
LH REAR
(C2344323/26526)
RH HEAD
(C2344323/26526)
LH HEAD
(C2344323/26526)
RH GROUND
(C2344323/26526)
LH GROUND
(C2344323/26526)
RH HOPPER LH HOPPER
(C2344323/26526)
RH PLATFORM POLE
.7A
.7A
.7A
.7A
PREMIUM POLE LIGHTING GROUP (OPT)
(26526) (26526)
LH PLATFORM POLE
(26526)
RH FRONT POLE
(26526)
LH FRONT POLE
56-GY w/RD
57-BR
102-OR w/GN
106-BU
103-YL
104-GN
107-TN
105-OR
GROUND
FROM PAGE 1,2,4
PAGE 8
