2-44 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Theory of Operation
• Control Panel
Allows the user to view the printer status or execute operations via the LCD,
LED, and buttons.
Front
MCU
Fan
Main Power Switch
Interlock
Switch
LVPS
HVPS
IP Board
LED Driver Board
Control Panel
Rear
s6000-110
