Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-95
Error Messages and Codes
Check Unit ADC Sensor
This message indicates that the ADC Sensor needs cleaning.
Applicable Errors
• 092-310: ADC Sensor Dustiness Pre Warning
• 092-910: ADC Sensor Dustiness
Initial Actions
• Cycle printer power.
•Clean the ADC Sensor (page7-7).
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL7.2.2 ■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 Developer” on
page 10-16
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Developer” on
page 10-30
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Disconnect P/J14 on the MCU
Board.
Is the voltage across ground at
P/J14-1 and P/J14-9 on the MCU
Board +5 VDC?
Go to step 2. Replace the
MCU Board
(page 8-121),
then go to
step 2.
2 Does the error persist? Contact your
designated
field support for
assistance.
Complete.
