Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-69
Error Messages and Codes
RX Communication Errors
Applicable Error
034-750 to 034-768: Communication Error (RX communication error is
detected)
Initial Actions
Cycle printer power.
If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
IP Board, PL7.1.9
MCU Board, PL7.2.2
“Map 2 - WorkCentre 6015 MFP” on
page 10-22
“WorkCentre 6015 MFP Image
Processor Board” on page 10-32
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the connectors on the IP and
MCU Boards then cycle system
power.
Does the error persist?
Go to step 2. Complete.
2 Replace the IP Board (page 8-114
Does the error persist?
Replace the
MCU Board
(page 8-121).
Complete.
