Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-83
Error Messages and Codes
Paper Remain at Regi
Paper stuck in the registration section (or Main Paper Tray or Bypass Tray section)
of the Printer was detected.
Applicable Error
• 077-100: Paper Remain at Regi
Initial Actions
• Check the media path for obstructions or debris.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Sensor, PL2.3.5
■ Harness Assembly RKN SNS,
PL2.2.25/26
■ MCU Board, PL7.2.2
■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 Feeder” on
page 10-12
■ “Phaser 6000/6010 Drive” on
page 10-13
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Feeder” on
page 10-26
■ “WorkCentre 6015 MFP Drive” on
page 10-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check connectors P/J12 and P/J120
between the MCU Board and the
Registration Sensor.
Are the connectors secure?
Go to step 3. Reconnect the
connectors,
then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Disconnect the MCU Board P/J21
and the Registration Sensor P/J120.
Check the Harness Assembly RKN
SNS for continuity.
Is the harness damaged?
Go to step 4. Repair the
harness.
4 Disconnect the MCU Board P/J12.
Is the voltage across ground and
P/J12-1 +3.3VDC?
Replace the
Registration
Sensor
(page 8-65).
Replace the
MCU Board
(page 8-121).
