Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 3-71
Error Messages and Codes
Motor Error
The Main Drive Assembly has failed.
Applicable Error
• 042-325: Motor Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Drive Assembly, PL6.1.2
■ Main Motor Harness, PL6.1.7
■ MCU Board, PL7.2.2
■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 LVPS” on
page 10-11
■ “Phaser 6000/6010 Drive” on
page 10-13
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP LVPS” on
page 10-25
■ “WorkCentre 6015 MFP Drive” on
page 10-27
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check the connections between the
MCU Board P/J16 and the Main
Drive Assembly P/J160.
Are the connections secure?
Go to step 3. Reconnect the
connectors,
then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Is the Main Drive Assembly installed
correctly?
Go to step 4. Reseat the
Main Drive
Assembly, then
go to step 5.
4 Does the error persist when the
power is turned off and on?
Go to step 5. Complete.
