Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-57
Troubleshooting
WorkCentre 6015 MFP Fax/Scanner Diagnostic Test Descriptions
Tes t
Control Panel
(WorkCentre 6015N/NI
Color MFP)
Description
Information Tests FAX and Scanner components.
Scan Counter FB: 0x00000000
ADF: 0x00000000
Displays the scan counter value.
â– FB: Platen scans
â– ADF: ADF scans
Scanner Maintenance
White Balance White Balance Reports the result of white balance
which is performed while the printer
powers up.
Registration Param. This function adjusts the registration
parameters of the scanner.
Parameter Range Description
Regi ADF Lead -2.0 mm to 2.0 mm,
in 0.1 mm steps
Adjusts Registration of the ADF leading
edge.
Regi ADF Side -1.0 mm to 1.0 mm,
in 0.1 mm steps
Adjusts Registration of the ADF side
edge.
Regi FB Lead -2.0 mm to 2.0 mm,
in 0.1 mm step
Adjusts Registration of the flatbed
leading edge.
Regi FB Side -1.0 mm to 1.0 mm,
in 0.1 mm steps
Adjusts Registration of the flatbed side
edge.
Auto Registration Reports the result of auto registration
which is performed while the printer
powers up.
IIT I/O Check
â– FB Home Sensor
â– ADF Scan Sensor
â– ADF Document Sensor
â– ADF Cover Sensor
Tests the scanner sensors.
Scan Counter Clear This function clears the flat bed and
ADF counters.
Parameter Value Options
Pulse Dialing Enable Pulse Dialing
NOTE You can not select Pulse
dialing at the Fax
Setting Menu, only Tone
dial.
Disable, Enable
Pulse dial make/break
ratio
0: 30% / 70%, 1: 32% / 68%,
2: 33% / 67%, 3: 36% / 64%,
4: 38% / 62%, 5: 39% / 61%,
6: 40% / 60%, 7: 42%/ 58%
Enable 20 PPS DP
NOTE You can not select Pulse
20PPS dialing at the Fax
Setting Menu.
Disable, Enable
DTMF Tone DTMF high tone
level (-dB)
0: -3 dB, 1: -4 dB, 2: -5 dB, 3: -6 dB,
4: -7 dB, 5: -8 dB, 6: -9 dB, 7: -10 dB
DTMF high/low level
difference (dB)
0: 0 dB, 1: -1 dB, 2: -2 dB, 3: -3 dB,
4:- 4 dB, 5: -5 dB
DTMF Dialing
Speed (ms)
0: 70 ms, 1: 80 ms, 2: 85 ms,
3: 90 ms, 4: 95 ms, 5: 100 ms,
6: 105 ms, 7: 110 ms
