Xerox Phaser 6000 Service Manual

3-72 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
Fan Motor Failure
Fan motor failure.
Applicable Error
• 042-358: Fan motor failure
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
5 Check the Main Drive harness
continuity.
Disconnect P/J16 from the MCU
Board and P/J160 from the Main
Drive Assembly to check continuity.
Is the harness damaged?
Repair the
harness.
Go to step 6.
6 Check the power to the Main Drive
Assembly.
Disconnect connector P/J16 on the
MCU Board.
Are the voltages across ground at
P/J16-2 and P/J16-4 approximately
+24 VDC when the Interlock Switch
is closed?
Replace the
Main Drive
Assembly
(page 8-82).
Replace the
MCU Board
(page 8-121).
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ LVPS, PL 7.2.1
■ Fan, PL 7.1.2
■ MCU Board, PL7.2.2
■ “Map 2 - Phaser 6000/6010” on
page 10-8
■ “Phaser 6000/6010 Fuser” on
page 10-17
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Fuser” on
page 10-31
Troubleshooting Procedure Table
Step Actions and Questions Yes No
