Xerox Phaser 6000 Service Manual

3-52 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
Paper Size Mismatch
The size of paper in the Main Paper Tray, or Bypass Tray, does not match the
specified print size.
Applicable Error
• 024-958: Paper Size Match
Initial Actions
• Check that the correct paper is in the paper tray. Change the paper if
necessary.
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Registration Sensor, PL2.3.5
■ Harness Assembly RKN SNS,
PL2.2.25
■ MCU Board, PL7.2.2
■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 Feeder” on
page 10-12
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Feeder” on
page 10-26
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check connectors P/J12 and P/J120
between the MCU Board and the
Registration Sensor.
Are the connections secure?
Go to step 2. Securely
reconnect the
connectors,
then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Disconnect the MCU Board P/J12
and the Registration Sensor P/J120.
Check the Harness Assembly RKN
SNS for continuity.
Is the harness damaged?
Repair the
harness.
Go to step 4.
4 Disconnect the MCU Board P/J12.
Is the voltage across ground and
J12-1 +3.3 VDC?
Replace the
Registration
Sensor
(page 8-65).
Replace the
MCU Board
(page 8-121).
