Xerox Phaser 6000 Service Manual

10-12 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Wiring
Phaser 6000/6010 Feeder
MCU
PL7.2.2
+24V
FEED 1
1
2
MSI Feed Solenoid
PL6.1.10
P/J19
P/J12
4
5
6
Registration Sensor Harness PL2.2.25
Registration Sensor Harness PL2.2.26
NO PAPER SENSED (H) +3.3VDC
SG
P/J121
3
2
1
PULL UP +3.3VDC
No Paper Sensor
PL2.2.23
1
2
3
REGI SENSED (L) +3.3VDC
SG
3
2
1
PULL UP +3.3VDC
Registration Sensor
PL2.3.5
P/J120
P/J25
1
2
I/L +24VDC
REGI CL ON (L) +24VDC
Registration Clutch
PL2.3.7
s6000-165
Interlock
+24VDC
+3.3VDC
+3.3VDC
