Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 6-11
Adjustment and Calibration
Scanner Adjustment
When the Scanner or the IP Board are replaced, the Scanner calibration data must
be written to the IP Board for proper Scanner operation. The WorkCentre 6015
MFPs have a Gap Serial Number sticker located at the center rear of the scanner.
This number is the calibration data that is required.
1. Connect the printer to the computer via USB.
2. Start the Grande Gap Writer software.
3. Choose the Scanner from the Scanner List.
4. Enter the Gap Serial Number in the Gap SN box and press Enter.
The information is written to the IP Board.
s6015-102
042840393736383A373E3637352A5F000000
