Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 2-25
Theory of Operation
Major Printer Components
In this section, major functional components of the printer are described with
illustrations.
These components are classified into the following functional blocks.
•Sensors
• Main Paper Tray
• Registration Assembly
•Process Control Sensors
•LED Print Head
• Toner Cartridge
• Xerographic Assembly
•Fuser & Exit
•Drive Assemblies
•Electrical
• Scanner
• Automatic Document Feeder (ADF)
