Xerox Phaser 6000 Service Manual

3-106 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
Fax Board Modem Error
A Fax Board error is detected.
Applicable Error
• 134-211
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.1.9
■ Fax Board, PL7.1.22
■ Fax Harness. PL7.1.22
■ MCU Board, PL7.2.2
■ “Map 2 - Phaser 6000/6010” on
page 10-8
■ “Phaser 6000/6010 Image Processor
Board” on page 10-18
■ “Map 2 - WorkCentre 6015 MFP” on
page 10-22
■ “WorkCentre 6015 MFP Image
Processor Board” on page 10-32
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Disconnect the Fax Harness at P/J2
on the IP Board and the
corresponding P/J on the Fax Board.
Check the Fax Harness for
continuity.
Is the cable continuos?
Go to step 3. Replace the
Fax Harness,
then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Replace the IP Board.
Does the error persist?
Replace the
MCU Board
(page 8-121).
Complete.
