Xerox Phaser 6000 Service Manual

3-96 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
ADC Sensor Error
An ADC Sensor error is detected.
Applicable Error
• 092-651: ADC Sensor Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ MCU Board, PL7.2.2 ■ “WorkCentre 6015 MFP Xerographics”
on page 10-28
■ “Phaser 6000/6010 Xerographics” on
page 10-14
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Clean the ADC sensor (page 7-7).
Does the error persist when the
power is turned on?
Go to step 2. Complete.
2 Disconnect the harness at MCU
Board P/J14 and at xerographics
assembly P/J140, and check the
harness for continuity.
Is the harness continuous?
Go to step 3. Repair the
harness.
3 Replace the MCU Board
(page 8-121).
Does the error persist when the
power is turned on?
Contact your
designated
field support for
assistance.
Complete.
