Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 2-17
Theory of Operation
Media Handling
Media Path
Multiple Sheet Feed
Prevention
Registration Assembly
IBT Belt Assembly
Fuser Assembly
Exit Roller in the Fuser Assembly
Top Cover
Bypass
Motor Drive / Solenoid /
Feed Roller
Multiple Sheet Feed
Prevention
Main
Motor Drive / Solenoid /
Feed Roller
Motor Drive / Clutch /
Registration Roller
Motor Drive / Belt /
2nd BTR
Motor Drive / Heat Roller /
Pressure Belt
Leading Edge
Registration
s6000-079
