Xerox Phaser 6000 Service Manual

8-4 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Service Parts Disassembly
Notations in the Disassembly Text
• The notation “(item X)” points to a numbered callout in the illustration
corresponding to the disassembly procedure being performed.
•The notation “PLX.X.X” indicates the component is listed in the Parts List.
• Arrows in an illustration show direction of movement when removing or
replacing a component.
• The notation “(tap, plastic, 10 mm)” or “(metal, 6 mm)” refer to the type of
screw being removed.
Replacement Note
Provides information specific to the replacement of parts or assemblies.

Xerox Phaser 6000 Specifications

General

Brand	Xerox
Model	Phaser 6000
Category	Printer
Language	English
