Error Messages and Codes
Scanner Motor Error
Applicable Error
• 062-322: Scanner Motor Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board, PL7.1.9
■ MCU Board, PL7.2.2
■ Scanner, PL8.1.1
■ “Map 2 - WorkCentre 6015 MFP” on
page 10-22
■ “WorkCentre 6015 MFP Image
Processor Board” on page 10-32
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Reseat the connectors on the IP and
MCU Boards then cycle system
power.
Does the error persist?
Go to step 2. Complete.
2 Replace the IP Board (page 8-114).
Does the error persist?
Replace the
MCU Board
(page 8-121),
then go to
step 3.
Complete.
3 Does the error persist? Replace the
Scanner
(page 8-35).
Complete.
