2-68 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Theory of Operation
Main Drive Assembly
Paper Feed Drive Flow
The torque of the Main Drive Assembly is transmitted through the route shown in
the following illustration.
Motor Drive Assembly
Main Motor
Gear PF1
Gear PF2
[ Name of moving parts ]
Gear HR
Gear Idler HR
[ Heat Roller ]
Registration Clutch
Gear PH6 Gear PH4
MPT Feed Solenoid
Gear PH5
[ Exit Roller ]
Fuser
Gear Idler Exit
Gear Exit
[ Feed Roller ] [ Regi Roller ]
Registration AssemblyMPF & PSI
Gear Feed
Gear PH3 Gear F3
Gear F4
PH Drive Assembly
