Xerox Phaser 6000 Service Manual

8-14 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Service Parts Disassembly
Transfer Roller
PL1.1.7~9
1. Open the Rear Door.
2. Unclip the Left Transfer Roller Bearing (white), then rotate it and pull it off of
the Transfer Roller.
3. Unclip the Right Transfer Roller Bearing (black), then rotate it and pull it off of
the Transfer Roller.
4. Remove the Transfer Roller from the printer.
Replacement Note
The Right Transfer Roller Bearing is installed over the spring.
s6000-032
