Xerox Phaser 6000 Service Manual

3-26 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Error Messages and Codes
Main Motor Failure
Applicable Error
• 007-340: Fuser Error
Initial Actions
• Cycle printer power.
• If the problem persists, use the following procedure.
6 Replace the ADF (page 8-37).
Does the error persist?
Replace the IP
Board
(page 8-114).
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Main Drive Assembly, PL6.1.2
■ Harness Assembly Main MOT,
PL 6.1.7
■ MCU Board, PL7.2.2
■ “Map 3 - Phaser 6000/6010” on
page 10-9
■ “Phaser 6000/6010 Fuser” on
page 10-17
■ “Map 3 - WorkCentre 6015 MFP” on
page 10-23
■ “WorkCentre 6015 MFP Fuser” on
page 10-31
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 Check these connections
■ MCU Board P/J16
■ Main Drive Assembly P/J160
Are the connectors secure?
Go to step 3. Secure the
connectors
and then go to
step 2.
2 Does the error persist? Go to step 3. Complete.
3 Check the Main Drive Assembly for
rotation. For the 6000B, see “Digital
Output Test Procedures” on
page A-16, or for the 6015 MFPs, see
“WorkCentre 6015 MFP Motor Test
Procedures” on page 4-50.
Does the Main Drive Assembly
function normally?
Replace the
MCU Board
(page 8-121).
Go to step 4.
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
