2-48 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Theory of Operation
Major Functional Components of the Image Input Terminal (IIT)
s6015-022
Control Panel
Assembly
Fax Board
IP Board
Carriage Motor
Scanner Board
Scanner Home
Position Sensor
Carriage
Assembly
USB Board
