2-58 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Theory of Operation
s6015-041
Front
Gear Shaft
: Indicates the engagement of gears.
[ Name of moving parts ]
ADF Motor
Feed Gear
Deceleration
[ Takeaway Roller ]
Pickup Gear
Deceleration
[ Exit Roller ]
[ Feed Roller ]
Takeaway Roller Gear
[ Nudger Roller ]
Pickup Roller Gear
Exit Gear
Deceleration
Exit Roller Gear
Pickup Idle Gear
Pickup Roller Gear
Idler Gear
Idler Gear
