Xerox Phaser 6000 Service Manual

Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 4-63
Troubleshooting
Busy Tone
Detection
Enable Busy Tone Detection 0: Disable, 1: Enable
On duration (Max duration) 0~80 (10 ms)
On duration (Min duration) 0~30 (10 ms)
Off duration (Max duration) 0~80 (10 ms)
Off duration (Min duration) 0~30 (10 ms)
No. of cycle for busy
condition
0: 3, 1: 4, 2: 5, 3: 6
Power Threshold 0: 35 dB, 1: 36 dB, 2: 37 dB,
3: 38 dB, 4: 39 dB, 5: 40 dB,
6: 41 dB, 7: 42 dB, 8: 43 dB,
9: 44 dB, 10: 45 dB, 11: 46 dB,
12: 47 dB, 13: 48 dB,
14: 49 dB, 15: 50 dB
TEL/FAX Power Threshold 0: -22 dB, 1: -24 dB, 2: -26 dB,
3: -28 dB, 4: -30 dB, 5: -32 dB,
6: -34 dB, 7: -36 dB
Dial Tone
Detection
Enable Dial Tone Detection 0: Disable, 1: Enable
Validation time 6~30 (100ms)
Power Threshold 0: 35 dB, 1: 36 dB, 2: 37 dB,
3: 38 dB, 4: 39 dB, 5: 40 dB,
6: 41 dB, 7: 42 dB, 8: 43 dB,
9: 44 dB, 10: 45 dB, 11: 46 dB,
12: 47 dB, 13: 48 dB,
14: 49 dB, 15: 50 dB
Call Progress
To ne
Freq. Filter
Call Progress Tone Freq. Filter 0: 340 Hz ~ 560 Hz
1: 310 Hz ~ 485 Hz
2: 363 Hz ~ 502 Hz
3: 276 Hz ~ 504 Hz
4: 415 Hz ~ 460 Hz
5: 310 Hz ~ 640 Hz
6: 370 Hz ~ 525 Hz
RX Power Rx Call Detection level 0: -36 dB, 1: -37 dB, 2: -38 dB,
3: -39 dB, 4: -40 dB, 5: -41 dB,
6: -42 dB, 7: -43 dB, 8: -44 dB,
9: -45 dB, 10: -46 dB, 11: -47 dB,
12: -48 dB
TX Power Tx Cable Equalizer 0: 0 dB, 1: 2 dB, 2: 4 dB, 3: 6 dB,
4: 8 dB, 5: 10 dB, 6: 11 dB,
7: 12 dB
Tx Signal Level 0: -3 dB, 1: -4 dB, 2: -5 dB,
3: -6 dB, 4: -7 dB, 5: -8 dB,
6: -9 dB, 7: -10 dB, 8: -11 dB,
9: -12 dB, 10: -13 dB, 11: -14 dB,
12: -15 dB, 13: -16 dB,
14: -17 dB, 15: -18 dB
Parameter Menu
Value/Options
