Phaser 6000/6010 and WC 6015 MFP Xerox Internal Use Only 5-27
Image Quality
4 Check the Registration Roller and
the Registration Pinch Roller for
rotation.
Using the Control Panel:
Put the printer in diagnostic mode
(see page 4-10) and select
■ Phaser 6010N:
Scroll to Engine Diag > Motor
Tes t > Re g i C l utc h > Motor >
Main Motor, and press OK.
■ WorkCentre 6015 MFP:
Scroll to Printer > IOT Diag >
Digital Output > DO-0, and press
OK.
CE Diagnostics can also be used to
perform this test by running the
Registration Clutch check. See
“Digital Output Test Procedures” on
page A-16.
Do the Registration Roller and the
Registration Pinch Roller rotate
correctly?
Complete. Go to step 5.
5 Replace the Registration Clutch
(page 8-66), and then perform the
test in step 4.
Do the Registration Roller and the
Registration Pinch Roller rotate
correctly?
Go to step 8. Go to step 6.
6 Replace the Feed Drive Assembly
(page 8-91), and then perform the
test in step 4.
Do the Registration Roller and the
Registration Pinch Roller rotate
correctly?
Go to step 8. Go to step 7.
7 Replace the Main Drive Assembly
(page 8-82).
Does the image print correctly?
Complete. Go to step 8.
8 Replace the Fuser (page 8-80).
Warning: Allow the Fuser to cool
before removing it.
Does the image print correctly?
Complete. Go to step 9.
9 Replace the Separator Pad
(page 8-49).
Does the image print correctly?
Complete. Go to step 10.
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
