5-30 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Image Quality
6 Inspect the Registration Roller and
the Registration Pinch Roller for wear
or damage.
Is either part worn or damaged?
Replace the
Registration
Roller
(page 8-61) or
the
Registration
Pinch Roller
(page 8-57),
then go to
step 7.
Go to step 8.
7 Does the image print correctly? Complete. Go to step 8.
8 Replace the Separator Pad
(page 8-49).
Does the image print correctly?
Complete. Go to step 9.
9 Replace the MCU Board
(page 8-121).
Does the image print correctly?
Complete. Contact your
designated
field support for
assistance.
Troubleshooting Procedure Table (Continued)
Step Actions and Questions Yes No
