9-28 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Parts List 6.1 Drive
Item Parts name Part Number
1 Drive Assembly MU
2 Drive Assembly MOT (Main Drive Assembly) 007K 17072
3 Gear F3 (F3 Drive Gear) 807E 32380
4 Gear PH3 (PH3 Drive Gear) 807E 32390
5 Drive Assembly PH (Feed Drive Assembly) 007K 17091
6 Drive Assy Deve (Developer Drive Assembly) 007K 17087
7 Harness Assembly Main MOT (J16-J160)
8 Gear Feed
9Spring Feed
10 Solenoid Feed (Feed Solenoid) 121E 22671
99 Drive Assembly Mot (With 2, 3, 4, and 5) (Main Drive
Assembly Kit)
604K 64630
To Next Page
