9-30 Xerox Internal Use Only Phaser 6000/6010 and WC 6015 MFP
Parts List
Parts List 7.1 Phaser 6000/6010 Electrical (1/2)
Item Parts name Part Number
1Duct Fan
2 Fan Main (Fan) 127E 86170
3 Guide Harness Drive (Drive Harness Guide)
4Plate Bitz
5 PWB Assy TOKI (LED Driver Board) 960K 54361
6 FFC Assy Light Biz (LED/MCU Cable) 962K 79920
7A Harness Assembly TOKI (6000B model) (LED Driver
Board Harness)
962K 84860
7B Harness Assembly TOKI (6010N model) (LED Driver
Board Harness)
962K 81970
8PLATE ESS IOT
9 PWBA ESS (6010N model) (IP Board) 676K 12210
10 —
11 Guide Harness Main Paper Tray (Main Paper Tray
Harness Guide)
12 —
15 Plate ESS IOT LT (6000B model)
16 PWBA ESS LT (6000B model) (IP Board) 676K 12200
To Next Page
