5.1 A: Initialization
144 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
Setting 3330: 3-Wire Initialization
The drive parameters are returned to factory default values with digital inputs S1, S2, and S5 configured as Run, Stop,
and Forward/Reverse respectively. Also refer to digital input functions, Setting 0: 3-Wire Sequence on page 236.
Setting 5550: oPE04 Reset
If parameters on a certain drive have been edited and then a different terminal block is installed with different settings
saved in its built-in memory, an oPE04 error will appear on the display. To use the parameter settings saved to the
terminal block memory, set A1-03 to 5550.
Notes on Parameter Initialization
The parameters shown in Table 5.1 will not be reset when the drive is initialized by setting A1-03 = 2220 or 3330.
Although the control mode in A1-02 is not reset when
A1-03 is set to 2220 or 3330, it may change when an application
preset is selected.
Table 5.1 Parameters not Changed by Drive Initialization
A1-04, A1-05: Password and Password Setting
A1-04 is for entering the password when the drive is locked. A1-05 is a hidden parameter used to set the password.
How to use the Password
The user can set a password for the drive to restrict access. The password is set to A1-05 and must be entered to A1-04 to
unlock parameter access. Until the correct password is entered, the following parameters cannot be viewed or edited:
A1-01, A1-02, A1-03, A1-06, A1-07, and A2-01 through A2-32.
The instructions below demonstrate how to set a new password
. Here, the password set is “1234”. An explanation
follows on how to enter the password to unlock the parameters.
Table 5.2 Setting the Password for Parameter Lock
No. Parameter Name
A1-00 Language Selection
A1-02 Control Method Selection
E1-03 V/f Pattern Selection
E5-01 Motor Code Selection (for PM motors)
E5-02 Motor Rated Power (for PM Motor)
E5-03 Motor Rated Current (for PM Motor)
E5-04 Number of Motor Poles (for PM Motor)
E5-05 Motor Stator Resistance (for PM Motor)
E5-06 Motor d-Axis Inductance (for PM Motor)
E5-07 Motor q-Axis Inductance (for PM Motor)
E5-09 Motor Induction Voltage Constant 1 (for PM Motor)
E5-24 Motor Induction Voltage Constant 2 (for PM Motor)
F6-/F7- Communication parameter (initialized when F6-08 = 1)
L8-35 Installation Selection
o2-04 Drive/kVA Selection
No. Parameter Name Setting Range Default
A1-04
Password
0000 to 9999 0000
A1-05
Password Setting
Step Display/Result
1. Turn on the power to the drive. The initial display appears.
2.
Press the or key until the Param
eter Setting Mode screen appears.
- MODE -
U1-01= 0.00Hz
U1-02= 0.00Hz
U1-03= 0.00A
DRV
FREF (OPR)
Rdy
JOG FWD FWD/REV
LSEQ
LREF
HELP
- MODE - PRG
DATA
Programming
FWD
