YASKAWA A1000 Technical Manual

B.7 Parameters that Change with the Motor Code Selection (for PM Motors)
532 YASKAWA ELECTRIC SIEP C710616 27G YASKAWA AC Drive A1000 Technical Manual
Table B.15 400 V, 1750 min
-1
Type YASKAWA SSR1 Series IPM Motor
No.
<6> Default setting value varies by the drive model (o2-04).
Name Unit Default Settings
E5-01
Motor Code Selection (for PM Motors)  1232 1233 1235 1236 1238 123A 123B 123D 123E 123F
Voltage Class V 400 400 400 400 400 400 400 400 400 400
Rated Power kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18
Rated Speed
min
-1
1750 1750 1750 1750 1750 1750 1750 1750 1750 1750
E5-02 Motor Rated Power (for PM Motors) kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0 15 18.50
E5-03 Motor Rated Current (for PM Motors) A 0.89 1.56 2.81 4.27 7.08 10.31 13.65 20.7 27.5 33.4
E5-04 Number of Motor Poles (for PM Motors) – 6 6 6 6 6 6 6 6 6 6
E5-05
Motor Stator Resistance (r1) (for PM
Mo
tors)
 25.370 9.136 6.010 3.297 1.798 0.982 0.786 0.349 0.272 0.207
E5-06
Motor d-Axis Inductance (Ld) (for PM
Mo
tors)
mH 169.00 92.08 67.71 34.40 32.93 22.7 16.49 13.17 10.30 8.72
E5-07
Motor q-Axis Inductance (Lq) (for PM
Mo
tors)
mH 197.50 119.56 81.71 54.00 37.70 26.80 23.46 15.60 12.77 11.22
E5-09
Motor Induction Voltage Constant 1 (Ke)
(f
or PM Motors)
mVs/rad 392.6 440.6 478.3
466.3 478.8 478.1 520.0 481.5 498.8 509.5
E5-24
Motor Induction Voltage Constant 2 (Ke)
(f
or PM Motors)
mV/(min
-1
)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Maximum Output Frequency
min
-1
(Hz)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(
87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
E1-05 Maximum Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency
min
-1
(Hz)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
E1-09 Minimum Output Frequency
min
-1
(Hz)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
C5-17 Motor Inertia
kgm
2
0.0011 0.0017 0.0023 0.0043 0.0083 0.014 0.017 0.027 0.046 0.055
L3-24
<6>
Motor Acceleration Time for Inertia
Calculations
s 0.092 0.076 0.052 0.066 0.075 0.083 0.077 0.084 0.102 0.101
n5-02 Motor Acceleration Time s 0.092 0.076 0.052 0.066 0.075 0.083 0.077 0.084 0.102 0.101
n8-49
d-Axis Current for High Efficiency
C
ontrol (for PM Motors) (OLV/PM)
% -8.6 -11.5 -10.3 -19.8 -8.5 -11.0 -18.6 -12.5 -15.5 -17.9
No.
<6> Default setting value varies by the drive model (o2-04).
Name Unit Default Settings
E5-01
Motor Code Selection (for PM Motors)  1240 1242 1243 1244 1245 1246 1247 1248 1249 124A
Voltage Class V 400 400 400 400 400 400 400 400 400 400
Rated Power kW22303745557590110132160
Rated Speed
min
-1
1750 1750 1750 1750 1750 1750 1750 1750 1750 1750
E5-02 Motor Rated Power (for PM Motors) kW 22.00 30.00 37.00 45.00 55.00 75.00 90.00 110.00 132 160
E5-03 Motor Rated Current (for PM Motors) A 39.8 52.0 65.8 77.5 92.7 126.6 160.4 183.3 222.9 267.7
E5-04Number of Motor Poles (for PM Motors)–6666666666
E5-05
Motor Stator Resistance (r1) (for PM
Motors)
 0.148 0.235 0.079 0.054 0.049 0.029 0.019 0.017 0.012 0.008
E5-06
Motor d-Axis Inductance (Ld) (for PM
Motors)
mH 6.81 5.4 4.08 3.36 3.16 2.12 1.54 1.44 1.21 0.97
E5-07
Motor q-Axis Inductance (Lq) (for PM
Motors)
mH 8.47 7.26 5.12 3.94 3.88 2.61 2.06 2.21 1.46 1.28
E5-09
Motor Induction Voltage Constant 1 (Ke)
(for PM Motors)
mVs/rad 503.9 561.7 528.5 558.1 623.8 594.5 524.1 583.7 563.6 601.2
E5-24
Motor Induction Voltage Constant 2 (Ke)
(for PM Motors)
mV/(min
-1
)
0.0 0.0 0.0 0.0 0.0 0.0 0.0 0.0 0 0
E1-04 Maximum Output Frequency
min
-1
(Hz)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
E1-05 Maximum Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380.0 380 380
E1-06 Base Frequency
min
-1
(Hz)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
1750
(87.5)
E1-09 Minimum Output Frequency
min
-1
(Hz)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
88
(4.4)
C5-17 Motor Inertia
kgm
2
0.064 0.116 0.140 0.259 0.31 0.42 0.56 0.83 0.96 1.61
L3-24
<6>
Motor Acceleration Time for Inertia
Calculations
s 0.098 0.130 0.127 0.193 0.191 0.187 0.208 0.254 0.243 0.338
n5-02 Motor Acceleration Time s 0.098 0.130 0.127 0.193 0.191 0.187 0.208 0.254 0.243 0.338
n8-49
d-Axis Current for High Efficiency
Control (for PM Motors) (OLV/PM)
% -15.1 -16.8 -14.1 -8.8 -9.6 -10.3 -17.0 -21.7 -10.9 -13.2
