Closed-Loop Crimp Terminal Recommendations
YASKAWA recommends using closed-loop crimp terminals on all drive models. UL approval requires the use of UL
Listed crimp terminals when wiring the drive main circuit terminals on models CIMR-A2A0110 to 2A0415 and
4A0
058 to 4A1200. Use only crimping tools as specified by the crimp terminal manufacturer. YASKAWA recommends
crimp terminals made by JST and Tokyo DIP (or equivalent) for the insulation cap.
Table D.7 matches the wire gauges and terminal screw sizes with
YASKAWA - recommended crimp terminals, tools, and
insulation caps. Refer to the appropriate Wire Gauge and Torque
Specifications table for the wire gauge and screw size
for your drive model. Place orders with a YASKAWA representatives or the YASKAWA sales department.
Table D.7 Closed-Loop Crimp Terminal Size
Drive Model
Wire Gauge (AWG, kcmil)
Screw
Size
Crimp Terminal
Model Number
Tool
Insulation Cap
Model No.
Code <2>
R/L1S/L2T/L3 U/T1V/T2W/T3 Machine No. Die Jaw
200 V Class Three-Phase Drives
2A0004
2A0006
2A0008
2A0010
14 <1>
M4
R2-4
YA -4 AD-900
TP-003 100-054-028
12
R5.5-4 TP-005 100-054-029
10
2A0012
14 14
<1>
M4
R2-4
YA -4 AD-900
TP-003 100-054-028
12 <1> 12
R5.5-4 TP-005 100-054-029
10
2A0018
– 14
M4
R2-4
YA -4 AD-900
TP-003 100-054-028
12
R5.5-4 TP-005 100-054-029
10
<1>
2A0021
12
M4 R5.5-4 YA - 4 AD-900 TP-005 100-054-029
10
<1>
2A0030
10
M4
R5.5-4
YA -4
AD-900 TP-005 100-054-029
8 <1> 8-4 AD-901 TP-008 100-054-031
6 14-NK4 AD-902 TP-014
100-054-033
2A0040
8 8 <1>
M4
8-4
YA -4
AD-901 TP-008 100-054-031
6
<1> 6 14-NK4 AD-902 TP-014 100-054-033
2A0056
6
M6
R14-6
YA -5
AD-952 TP-014 100-051-261
4
<1> R22-6 AD-953 TP-022 100-051-262
2A0069
4
M8
R22-8
YA -5
AD-953 TP-022 100-051-263
3
<1> R38-8 AD-954 TP-038 100-051-264
2A0081
3
M8 R38-8 YA- 5 AD-954 TP-038 100-051-264
2
<1>
2A0110
3
M8
R38-8 YA -5 AD-954 TP-038 100-051-264
2
1
R60-8 YA -5 AD-955 TP-060 100-051-265
1/0
<1>
2A0138
1
M10
R60-10
YF-1
YET
-300-1
TD-321,
TD-311
TP-060 100-051-266
1/0
2/0
<1> R80-10
TD-323,
TD-312
TP-080 100-051-267
2A0169
2/0 –
M10
R80-10
YF-1
YET
-300-1
TD-323,
TD-312
TP-080 100-051-267
3/0
4/0
<1> R100-10
TD-324,
TD-312
TP-100
100-051-269
2A0211
1/0  2P <1>
M10
R60-10
YF-1
YET
-300-1
TD-321,
TD-311
TP-060 100-051-266
2/0  2P R80-10
TD-323,
TD-312
TP-080
100-051-267
2A0250
3/0  2P
<1>
M12
80-L12
YF-1
YET-300-1
TD-323,
TD-312
TP-080 100-051-558
4/0  2P 100-L12
TD-324,
TD-312
TP-100 100-051-560
– 250  2P 150-L12
TD-325,
TD-313
TP-150 100-051-562
250 –
R150-12 TP-150 100-051-273
300
2A0312
3/0  2P 3/0  2P
<1>
M12
80-L12
YF-1
YET-300-1
TD-323,
TD-312
TP-080 100-051-558
4/0  2P
<1> 4/0  2P 100-L12
TD-324,
TD-312
TP-100 100-051-560
250  2P
150-L12
TD-325,
TD-313
TP-150 100-051-562
300  2P
