Explanation
With this feature, you can make the DL6000/DLM6000 trigger when the specified relationship is
established between the reference times and the length of time for which a condition is met or not met.
Time Width Mode (Mode)
You can make the DL6000/DLM6000 trigger when the specified relationship between the reference
times and the pulse width of a single trigger source is established. You can specify one of the following
relationships.
More than The DL6000/DLM6000 triggers when the pulse width is longer than the specified
reference time and the condition changes.
Less than The DL6000/DLM6000 triggers when the pulse width is shorter than the
specified reference time and the condition changes.
Between The DL6000/DLM6000 triggers when the pulse width is longer than T1 and
shorter than T2 and the condition changes.
Out of Range The DL6000/DLM6000 triggers when the pulse width is shorter than T1 or
longer than T2 and the condition changes.
Time Out The DL6000/DLM6000 triggers when the pulse width is longer than the specified
reference time.
Reference Times (Time)
You can set each of the reference times to a value from 1.0 ns to 10.0000 s in 0.5 ns steps.
Note
The DL6000/DLM6000 may not trigger properly if the spacing between signals or the signal pulse width is
less than 2 ns. Under standard operating conditions, the pulse width accuracy is ±(0.2% of the set value + 1
ns) immediately after calibration. The “set value” in the above expression is the T2 value when T1 < Pulse <
T2.
