YOKOGAWA DL6000 Series User Manual

Triggering
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
6-59
IM DLM6054-01EN
Explanation
The DL6000/DLM6000 determines whether the acquired waveform meets the reference conditions
(NO-GO result) or not (GO result). When the DL6000/DLM6000 produces a NO-GO result, it executes
the specified actions.
You can specify up to four determination conditions. You can also apply AND or OR logic to the four
determination conditions.
You can use the following types of zones as determination conditions.
Rectangular, waveform, and polygonal zones
GO/NO-GO Determination Mode (Action on TRIG)
You can set the GO/NO-GO determination mode to one of the settings below.
• OFF: The DL6000/DLM6000 will acquire the number of signals specified by ACQ Count and then
stop.
• All Condition: The DL6000/DLM6000 executes the specified actions whenever a trigger occurs (see
section 6.13 for details).
• Zone/Parameter (GoNogo):
Select this mode when you want to perform GO/NO-GO determination using a zones or parameter.
• Mask (GoNogo): Select this mode when you want to perform GO/NO-GO determination using a
mask test or eye pattern (see section 6.17 for details).
Determination Logic (Logic)
You can set the determination logic for determination condition numbers 1 to 4.
• AND: The DL6000/DLM6000 executes the specified actions whenever all the determination
conditions are NO-GO.
• OR:
The DL6000/DLM6000 executes the specified actions whenever any of the determination
conditions are NO-GO.
Determination Condition Numbers (Select)
For determination conditions 1 to 4, set the source waveform, determination range (the waveform zone
upper and lower limits), and the reference condition.
Determination Mode (Mode)
You can select the determination mode from the following options.
• Rect: You can create a rectangular zone by specifying upper, lower, left, and right limit values
and perform GO/NO-GO determination based on whether or not the waveform is within
the zone.
• W
AVE: You can create a zone based on a reference waveform and perform GO/NO-GO
determination based on whether or not the waveform is within the zone.
• Polygon:
You can load a polygonal zone that you have created on a PC and perform GO/NO-GO
determination based on whether or not the waveform is within the zone (see section 6.19
for details).
• Parameter:
See section 6.16 for details.
Reference Condition (Condition)
Select whether the source waveform must be in or out of the determination range to produce a NO-GO
result.
• IN:
Waveforms that are inside of the determination range are detected.
• OUT: Waveforms that are outside of the determination range are detected.
• X: The source waveform is not used for GO/NO-GO determination.
Determination Source Window
You can select the determination source window from the following options. However, you cannot set
the determination source window to XY1 or XY2 when you are using a waveform zone.
• Main:
GO/NO-GO determination is performed on the waveform in the main window.
• Zoom1: GO/NO-GO determination is performed on the waveform in the Zoom1 window.
• Zoom2: GO/NO-GO determination is performed on the waveform in the Zoom2 window.
• XY1: GO/NO-GO determination is performed on the waveform in the XY1 window.
• XY2: GO/NO-GO determination is performed on the waveform in the XY2 window.
6.15 Performing GO/NO-GO Determination with Zones
