6-62
IM DLM6054-01EN
Actions to Execute When Conditions Are Met (Action)
The DL6000/DLM6000 executes the specified actions each time the conditions are met. You can
specify any of the four actions below.
Buzzer (Buzzer)
The DL6000/DLM6000 generates an alarm.
Print or Save the Screen Image (Print)
The DL6000/DLM6000 prints the screen image to the printer specified by “Copy to” in the PRINT
menu or stores the screen image data to the specified storage medium. The available printer
options are Built-in Printer, USB Printer, and Network Printer.
Save the Measured Data (Save to File)
The DL6000/DLM6000 saves the measured data to the save destination specified in the FILE
menu. You can choose to save the data in binary, ASCII, or floating point format. The format that the
data is saved in depends on the data type setting in the FILE menu.
Send E-mail (Mail)
The DL6000/DLM6000 sends an e-mail to the specified addresses (if it is equipped with the
Ethernet interface option).
T
o set the e-mail addresses, see “Configuring E-Mail Transmission” in Chapter 14.
Mail Transmission Operations
• Enabling and Disabling Mail Transmission (Mode)
When Mode is ON, e-mails will be sent to the addresses specified in: UTILITY menu > Network >
E-mail Setup > Address (To Address/From Address).
• E-mail Transmission Interval (Interval)
The DL6000/DLM6000 will send an e-mail at the first NO-GO result after the interval specified
here elapses. An e-mail will also be sent when GO/NO-GO determination stops (stopping
includes manual stops).
The range of e-mail transmission intervals that you can set is i
ndicated below. If you select OFF,
an e-mail will be sent whenever a NO-GO result occurs.
OFF to 1440 min (in 1 min. steps)
6.15 Performing GO/NO-GO Determination with Zones
To Next Page
