YOKOGAWA DL6000 Series User Manual

Triggering
3
2
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
Index
App
6-67
IM DLM6054-01EN
Using FFT Parameters for Determination
Set the number of the analysis that you want to use for determination (1, 2).
Press to set the FFT parameter to use for determination.
Set the upper and lower limits of the determination range.
Switches the item that the jog shuttle adjusts (between Upper and Lower).
Selecting Which Parameter to Use for Determination (Item)
Press the Item soft key to display the following menu.
Select if you want to use a standard analysis item
(Peak).
Select if you want to use a registered expression.
Select the check box of the item
you want to use for determination.
Using XY Parameters for Determination
Set the upper and lower limits of the determination range.
Set the number of the analysis that you want to use for determination (1, 2).
Switches the item that the jog shuttle adjusts (between Upper and Lower).
6.16 Performing GO/NO-GO Determination with Parameters
