YOKOGAWA DL7440 User Manual

6-39
IM 701450-01E
6
Triggers
Line Number
A trigger is activated at the start of the line of the selected number.
NTSC: 5 to 1054
The following line numbers are those when the field number is set to 1 (if the field
number is set to 2, the numbers are assigned sequentially by setting 268 to 5).
524 525
(1) (2) (3)(4) 5678910111213141516171819202122
23
Field 1
262 263 264265 266 267 268 269 270 271 272 273274 275 276277 278 279 280 281 282 283 284 285
Field 2
261
Line number
Line number
1049 1050
526 548
1051 1054
786 810
Line numbers inside the parentheses cannot be set.
PAL or SECAM: 2 to 1251
The following line numbers are those when the field number is set to 1 (if the field
number is set to 2, the numbers are assigned sequentially by setting 315 to 2).
621 622 623 624 625
234567(1)
Field 1
308 309 310 311 312 313 315314 316 318317 320319
Field 2
Line number
1246 1250
632
626
1251
Line number
933 945
Line numbers inside the parentheses cannot be set.
1080/60i, 1080/50i, or 1080/24sF: 2 to 2251
The following line numbers are those when the field number is set to 1 (if the field
number is set to 2, the numbers are assigned sequentially by setting 565 to 2).
1120 1125
(1) 2 3 4 5 6 7 41
5H 5H 35H
517H
45H
557 562 563 564 565 566 567 568 569 603
5H 5H 34H
518H
45H
1/2H 1/2H
Field 1
Field 2
Line number
2245 2250
1126 1127 1128 1129 1130 1131 1132 1166
2251
Line number
1682 1687 1688 1169 1170 1171 1172 1173 1174 1728
Line numbers inside the parentheses cannot be set.
1080/25p, 1080/24p, or 1080/60p: 2 to 2251
1125
(1) 234567
5H 5H 35H
45H
Line number
2250
1126 1127 1128 1129 1130 1131 1132
2251
Line numbers inside the parentheses cannot be set.
8
1133
720/60p: 2 to 2251
750
(1) 234567
5H 5H 20H
30H
Line number
2250
751 752 753 754 755 756 757
2251
Line numbers inside the parentheses cannot be set.
8
758
6.14 Setting the TV Trigger (ENHANCED)
