8-14 IM 701450-01E
Explanation
Display Mode
You can select the display mode.
T-Y&X-Y The top window displays T-Y (normal) waveforms. The bottom window
displays X-Y waveforms.
X-Y Displays only X-Y waveforms.
T-Y Displays only T-Y waveforms.
X-Axis Mode
You can select the X-axis mode.
Single
Sets the X-axis trace of XY1 and XY2 common.
Dual
Sets the X-axis trace of XY1 and XY2 separately.
Number of X-Y Waveforms That Can Be Displayed
The number of X-Y waveforms that can be displayed is 2 (XY1 and XY2). The display of
each X-Y waveform can be turned ON/OFF.
Assigning the X-Axis (Horizontal Axis) and Y-Axis (Vertical Axis)
The channels that can be assigned to the X and Y axes depending on the X-axis mode
are as follows:
X Axis Mode X-Y Waveform X-Axis Y-Axis
Single XY1 CH1 to CH4, Math1, Math2 CH1, CH2, and Math1
XY2 CH1 to CH4, Math1, Math2 CH3, CH4, and Math2
Dual XY1 CH1, CH2, Math1 CH1, CH2, and Math1
XY2 CH3, CH4, Math2 CH3, CH4, and Math2
X-Y Waveform Display Range
The X-Y waveform displays the range specified on the T-Y waveform. You can set the
start (fine dashed line) and end (coarse dashed line) positions in the range of –5 to +5
divisions from the center of the waveform display frame. The start and end points are
not displayed if only X-Y waveforms are displayed. The resolution is 10 divisions÷the
display record length.
Note
• The divided windows of the T-Y waveform display when using the T-Y & X-Y mode are
displayed according to Format in the DISPLAY menu.
• The zoom function applies only to T-Y waveforms. In addition, Main, Z1, or Z2 can be
selected for the T-Y waveform display.
• To expand the X-Y waveform, change the Variable setting of each channel. The displayed
waveform can be enlarged/reduced in a simulated fashion.
8.5 Displaying X-Y Waveforms
