Analyzing and Searching Waveforms
Note
• The measured values of the X-axis (horizontal axis and time axis) are displayed relative to the
trigger position.
• If measurement is not possible, *** is displayed in the measured value display area.
• Logic waveforms (optional) cannot be selected in horizontal cursor and marker cursor
measurements.
• When the T/div setting is not repetitive sampling mode and the acquisition mode is not
averaging mode, sampled data may not exist at the vertical cursor position in the interpolation
display
1
area. The measured value of the vertical cursor in this case is the value of the
sampled data closest to the cursor on the right. On the contrary, marker cursors always
move over the sampled data.
1
Interpolation display is used when there are less than 500 points of sampled data in 10
divisions along the X-axis or when the zoom waveform display format is Main&Z1&Z2 and
there are less than 250 points of sampled data in the zoom waveform display frame.
