10-75
IM 701450-01E
10
Analyzing and Searching Waveforms
Determination Operation, Waveform Acquisition Count, DL7400 Action When the
Condition Is Met, and Determination Range
They are the same as the GO/NO-GO determination using zones. See section 10.9.
Executing/Aborting GO/NO-GO Determination
• When executed, the determination count, the number of times the condition is met,
and the determination result, determination target waveform, measurement
parameter, and measured value of each determination parameter are displayed on
the screen.
• All keys other than the START/STOP key and the Abort soft key are disabled while
determination is in progress.
Note
• When GO/NO-GO determination is executed, the trigger mode is automatically set to “Single.”
• Determination is not possible when the acquisition mode is set to Average.
10.10 Performing GO/NO-GO Determination Using Measured Waveform Parameters
To Next Page
